| Application: | It is used when the boat is moored |
| Material: | Steel alloy metals |
| Specification: | 12 holes, 16 holes |
| Surface: | Anti-rust paint |
| Standard: | Adheres to the japanese industrial standard F2015 |
| Certification: | ISO9001, LR, ABS, DNV, BV, CCS, KR, RMRS, NK etc |
| Applicable dia. | 12.5-14 | 16-17.5 | 19-20.5 | 22-24 | 26-28 | 30-32 | 34-36 | 38-40 | 42-44 | 46-48 | 50-52 | 54-56 | 58-60 | 62-64 | 66-68 |
| B mm | 142 | 170 | 193 | 219 | 241 | 274 | 34 | 336 | 366 | 397 | 428 | 457 | 488 | 517 | 547 |
| H mm | 162 | 190 | 216 | 241 | 270 | 305 | 342 | 378 | 412 | 450 | 491 | 528 | 564 | 600 | 635 |
| L mm | 235 | 270 | 310 | 345 | 385 | 435 | 490 | 540 | 590 | 640 | 695 | 745 | 795 | 850 | 900 |
| Weight（kg） | 22 | 29 | 36 | 45.5 | 58 | 74 | 92 | 115 | 145 | 183 | 225 | 271 | 352.5 | 424 | 509 |
