| Material: | Cast steel or cast iron |
| Surface: | Sandblasting then painted epoxy or according to the customer's request. |
| Weight: | 30KG-2200KG |
| Color: | Colorful paint |
| Certification: | DIN81902,ISO9001,LR, ABS, DNV, BV, CCS, KR, RMRS, NK etc. |
| Diameter | Diameter(mm) | Weight | ||||||||||
| (mm) | A | B | C | D | E | F | G | H | I | K | L | (kg) |
| -12 | 180 | 100 | 650 | 80 | 446 | 170 | 10 | 465 | 208 | 80 | 356 | 75 |
| -16 | 230 | 130 | 800 | 100 | 546 | 210 | 10 | 575 | 258 | 100 | 446 | 130 |
| -20 | 250 | 130 | 900 | 120 | 626 | 250 | 15 | 655 | 308 | 120 | 506 | 220 |
| -24 | 280 | 160 | 1000 | 140 | 716 | 290 | 20 | 730 | 328 | 120 | 576 | 330 |
| -32 | 300 | 160 | 1200 | 180 | 836 | 366 | 25 | 855 | 398 | 140 | 676 | 580 |
| -40 | 320 | 180 | 1350 | 245 | 1030 | 500 | 35 | 1045 | 5050 | 180 | 830 | 1100 |
| -48 | 400 | 250 | 1700 | 300 | 1236 | 610 | 45 | 1260 | 583 | 200 | 1016 | 2210 |
